All Elcometer 456 coating thickness gauge probes are fully interchangeable and are available in a number of designs and scale ranges to meet your specific application.
Ferrous coating thickness gauge probes measure non magnetic coatings on ferro-magnetic substrates. Elcometer 456 coating thickness ferrous gauges accept any ferrous probe.
Non-ferrous coating thickness gauge probes measure non conductive coatings on non-ferrous metal substrates and Elcometer 456 non-ferrous gauges accept any non-ferrous probe.
Dual FNF probes measure both ferrous and non-ferrous applications with automatic substrate detection. Elcometer 456 FNF coating thickness gauges accept all ferrous, non-ferrous and dual FNF probes.
Elcometer 456 DFT Probes
Elcometer 456 Coating Thickness Gauge Probe Range Explained
Standard Straight Probes
Standard probes measure coatings on both flat and curved surfaces.
Mini Probes
Mini probes are ideal for harder to reach areas and edges.
Right Angle Probes
Designed for taking coating thickness readings where access is restricted.
PINIP™ Probes
Plug-in probes convert a separate coating thickness gauge into an integral gauge.
Telescopic Probes
Extending right angle probes for out of reach areas.
Scan Probes
These probes are fitted with replaceable probe caps – allowing users to take individual coating thickness measurements or scan large surface areas without damaging the probe.
Waterproof Probes
Sealed for use underwater at depth, even in diving gloves.
High Temperature Probes
For use on hot coated materials up to 250C (480F)
Anodising Probes
Chemical resistant washable probes – ideal for the anodising environment.
Armoured Cable Probes
Probes with metal reinforced heavy duty cables, reducing the risk of cable damage.
Soft Coating Probes
Large surface area probes for soft reach materials (HVCA approved).
Specialist Probes
These probes are designed for measuring coating thickness on specialist substrates, such as graphite, or electroplated components.
Elcometer probes have a maximum operating temperature of 80C (176F) with the exception of separate ferrous probes 150C (300F) and Hi-Temperature PINIP’s 250C (480F). The stated temperature is the substrate temperature, and the duty cycle of the probe must be reduced to ensure a minimal temperature build-up within the probe.
All Elcometer coating thickness gauge probes are supplied with a Test Certificate and a set of calibration foils appropriate to the scale range of the probe.
